單機設備
Stand alone equipment
設備描述
Used in food and beverage industry, chemical industry, etc.  Supporting the three-in-one filling line, etc., to stack all kinds of bottles and containers.  The automatic operation of the palletizer is divided into automatic feeding, transferring, sorting, piling, moving, lifting, supporting, stacking, stacking and other steps.
working principle
Forklift truck will stack the pallet full of empty tank, placed on the pallet conveyor, and then the conveyor will transport it to the pallet lifting platform of the main engine.  Pallet lifting platform is to lift the empty tank pallet after positioning to the unloading height, when the unloading of the empty tank, and then the empty pallet is lowered on the conveyor.  All the rising and falling actions are carried out by the self-locking lifting system device to push the tank, which pushes the empty tank of the whole layer to the net conveyor, and then returns to the ready position and continues to push out the next layer.  All movement positioning is controlled by photoelectric switch, and can choose continuous movement or single cycle unloading.
technical specification

Technical parameters

Empty tank piler

Device model JPXD-100

Dimensions length 10500× width 3000× height 3500 (unit mm)

Processing capacity of 500-1200 cans (bottles) per minute

Adapt to the object φ50-φ153mm, 50-270mm high

The equipment is suitable for all kinds of metal cans, plastic bottles, glass bottles

Applicable scope fruits, vegetables, medicinal materials, etc


設備特點
Especially suitable for code heat shrinkable film packaging products
Try to use 304 materials, beautiful and generous machine
Motor, cylinder drive and control are all imported brand components
Adopt high quality transmission chain section transmission, the output section can be arbitrarily extended
Multiple safety protection, with touch screen control
Adapt to a variety of stacks and bottles, easy to adjust
PLC control, automatic operation
Low - position into the box, occupy less space, large production capacity
